Realistic Ambient Occlusion Approximation for Skinned Characters Results

Walking Animation

Side by side comparison

You can click gifs to make them larger.

Walking Animation Ray Traced
Walking Animation Ray Traced Ground Truth

Joint angle approximation
Joint Angle Approximation

Clustered vertex approximation
Clustered Vertex Pos. Approximation

Errors

Max Error Min Error Mean of MSE (All frames) Variance of MSE (All frames)
Joint Angle Approximation 2.1207e-013 1.1046e-013 1.5471e-013 6.9689e-028
Clustered Vertex Pos. Approx. 1.2272e-004 7.0379e-005 8.9901e-005 2.1557e-010



Dying Animation

Side by side comparisons

You can click gifs to make them larger.

Dying Animation Ray Traced
Dying Animation Ray Traced

Joint Angle Approximation
Joint Angle Approximation

Clustered Vertex Pos. Approximation
Clustered Vertex Pos. Approximation

Regularization - Clustered Vertex (lambda = 0.00001)
Regularization – Clustered Vertex (lambda = 0.00001)

Errors

Max Error Min Error Mean of MSE (All frames) Variance of MSE (All frames)
Joint Angle Approximation 9.7189e-012 6.3975e-012 7.7733e-012 4.1774e-025
Clustered Vertex Pos. Approx. 0.0074 0.0029 0.0045 1.3020e-006
Regularization + Clustered Vertex Pos. (Lambda = 0.00001) 4.5722e-004 5.8359e-005 2.2995e-004 4.8963e-009

 Comparison of Different Lambda values

Dying / lambda = 0.01
Dying / lambda = 0.01

Dying / lambda = 0.001
Dying / lambda = 0.001

Dying / lambda = 0.0001
Dying / lambda = 0.0001

Dying / lambda = 0.00001
Dying / lambda = 0.00001


Max Error Min Error Mean of MSE (All frames) Variance of MSE (All frames)
Lambda = 0.01 6.8733e-004 1.1602e-004 3.8792e-004 1.2317e-008
Lambda = 0.001 5.6929e-004 7.5536e-005 3.0100e-004 7.7147e-009
Lambda = 0.0001 5.0294e-004 6.2022e-005 2.5159e-004 5.8135e-009
Lambda = 0.00001 4.5722e-004 5.8359e-005 2.2995e-004 4.8963e-009



Striking Animation

Side by side comparisons

You can click gifs to make them larger.

Striking Animation Ray Traced Ground Truth
Striking Animation Ray Traced Ground Truth

Joint Angle Approximation
Joint Angle Approximation

Clustered Vertex Pos. Approximation
Clustered Vertex Pos. Approximation

Regularization - Clustered Vertex (lambda = 0.00001)
Regularization – Clustered Vertex (lambda = 0.00001)



Errors

Max Error Min Error Mean of MSE (All frames) Variance of MSE (All frames)
Joint Angle Approximation 3.9038e-004 5.2763e-005 1.9546e-004 6.6443e-009
Clustered Vertex Pos. Approx. 0.0090 0.0046 0.0064 1.5406e-006
Regularization + Clustered Vertex Pos. (Lambda = 0.00001) 0.7365 0.6341 0.6847 0.0014

Comparison of Different Lambda values

Striking / lambda = 10000
Striking / lambda = 10000

Striking /lambda = 1
Striking /lambda = 1

Striking / lambda = 0.001
Striking / lambda = 0.001

Striking / lambda = 0-0001
Striking / lambda = 0.0001

Striking / lambda = 0.00001
Striking / lambda = 0.00001



Max Error Min Error Mean of MSE (All frames) Variance of MSE (All frames)
Lambda = 10000 0.7365 0.6341 0.6847 0.0014
Lambda = 1 0.7365 0.6341 0.6847 0.0014
Lambda = 0.001 0.7365 0.6341 0.6847 0.0014
Lambda = 0.0001 0.7365 0.6341 0.6847 0.0014
Lambda = 0.00001 0.7365 0.6341 0.6847 0.0014
